A 5mm thickness galvanized steel wire rope lanyard cable tether is a robust and durable solution for various applications requiring secure and flexible attachment. Here are some details and uses for this type of cable tether:
Specifications:
1. Wire Rope Construction:
- Strand Configuration: Common configurations include 7×7 (seven strands of seven wires each) or 7×19 (seven strands of nineteen wires each). The 7×19 configuration offers more flexibility and is often used in dynamic applications, whereas 7×7 is stiffer and used where less flexibility is required.
- Core: Can be either fiber core (FC) or independent wire rope core (IWRC). IWRC provides greater strength and resistance to crushing.
2. Galvanization:
- Process: The steel wire is coated with a layer of zinc through hot-dip galvanizing or electro-galvanizing. Hot-dip galvanizing provides a thicker, more durable coating.
- Zinc Coating: This protective layer helps prevent rust and corrosion, extending the life of the cable in harsh environments.
3. Dimensions:
- Diameter: 5mm (0.197 inches)
- Length: Customizable based on application needs, typically available in standard lengths or cut to specific requirements.
4. Breaking Strength:
- Tensile Strength: Depends on the wire rope construction and material quality. For a 5mm galvanized steel wire rope, the breaking strength can range between 15 to 25 kN (kilonewtons), equivalent to approximately 3,370 to 5,620 lbs.
5. Weight:
- Per Meter: Approximately 0.1 to 0.2 kg per meter, depending on the specific construction and core type.
Features and Benefits:
1. High Strength and Durability:
- Load-Bearing Capacity: Suitable for heavy-duty applications, providing a strong and reliable tethering solution.
- Longevity: Galvanized coating ensures the rope remains functional over long periods, even in challenging conditions.
2. Versatility:
- Multi-Purpose Use: Applicable across various industries and activities, from industrial and construction to marine and recreational uses.
- Customizable: Available in different lengths and with various end fittings to suit specific requirements.
3. Safety:
- Reliable Performance: Ensures safety in applications requiring secure attachment and support, such as safety harnesses and fall protection systems.
- Compliance: Meets industry standards and regulations for safety and performance.
Common End Fittings:
- Loops and Thimbles: Formed at the ends to create secure attachment points, often reinforced with thimbles to prevent wear.
- Swage Terminals: Metal fittings crimped onto the cable ends for secure and permanent attachment.
- Hooks and Clips: Used for easy and quick attachment and detachment.
- Turnbuckles: Allow for tension adjustment in the cable.
Applications in Detail:
1. Industrial and Construction:
- Cranes and Hoists: Used for lifting and moving heavy loads securely.
- Scaffolding: Ensures stability and safety in construction sites.
- Machinery: Secures heavy machinery during transport or operation.
2. Marine and Outdoor:
- Boat Rigging: Secures sails and other equipment on boats.
- Zip Lines and Adventure Parks: Provides a safe and strong support line for recreational activities.
3. Safety and Security:
- Fall Protection: Integral part of safety harness systems for workers in high-risk environments.
- Theft Prevention: Used in tethering valuable equipment and tools to prevent loss or theft.
4. Agriculture and Horticulture:
- Support Structures: Provides support for trellises and other plant support systems.
Installation and Maintenance:
- Installation:
- Proper Tools: Use appropriate tools and techniques to ensure secure attachment of end fittings and tensioning of the cable.
- Professional Installation: For critical applications, professional installation is recommended to ensure safety and compliance with standards.
- Maintenance:
- Regular Inspections: Check for signs of wear, corrosion, and damage regularly.
- Lubrication: Apply suitable lubricants to maintain flexibility and prevent corrosion, if not already coated.
- Replacement: Replace immediately if any signs of significant wear or damage are detected.
A 5mm galvanized steel wire rope lanyard cable tether offers a robust and versatile solution for many applications requiring strength, durability, and reliability.
